INPUT IMPEDANCE: 5K ohm
OUTPUT IMPEDANCE: 10K ohm
POWER CONNECTOR: 9Vdc, center negative, 2.1mm x 5.5mm
OPERATING VOLTAGE: 9Vdc
MAXIMUM VOLTAGE: 18Vdc
REVERSE BATTERY PROTECTION: Yes
OVER VOLTAGE PROTECTION: Yes
CURRENT CONSUMPTION: 9mA
ESTIMATED BATTERY LIFE: Approximately 60 hours of continuous use
DIMENSIONS: 2.5”(W) x 4.5”(D) x 1.25”(H)
WEIGHT: 0.75lb
FX LINK CONNECTOR: 1/8" Stereo
FX LINK MAX VOLTAGE: 3.3Vdc
SHIELD TIP: Activate Green (normal) Mode
SHIELD RING: Activate Red (fat) Mode
ROHS COMPLIANT: Yes
AGENCY APPROVALS: N/A
IDC: 1805171725164427
